Windows Set Up

Before connecting the Miura card reader to a Windows PC via USB, make sure that you have configured your Miura card reader for Windows.
You can connect the Miura card reader to a Windows PC via USB connection.
  1. Make sure the card reader is running in USB Serial Mode .
  2. Connect the card reader to the Windows PC using the USB cable.
  3. In the
    Device Manager
    of the Windows PC, the Miura should appear under
    Ports (COM & LPT)
    named
    Gadget Serial
    or
    PI USB to Serial
    as shown in the example below.
  4. On Windows 7 and 8.1 operating systems the Miura driver might not be automatically installed, causing the Miura to show up with status:
    The drivers for this device are not installed. (Code 28).
    In this case, perform the following steps to manually install the driver:
    1. Download the Miura USB Drivers and unzip them on the Windows PC
    2. In the Device Manager, select
      Update Driver...
      and then
      Browse my computer for driver software
    3. Select
      Let me pick from a list of device drivers on my computer
      >
      Show All Devices
      >
      Browse my computer for driver software
      >
      Have Disk...
    4. Locate
      miura-usb-serial.inf
      in the zipped files and the Miura should show up as a working in the Device Manager.
  5. Specify the
    COM Port
    when setting up the PayServer.
